The aluminum containers of the DS series from Auguste Cryogenics Medical Family are cryogenic freezer containers specially designed for the transport of biogenic material in liquid nitrogen. The special material inside the container absorbs the liquid nitrogen and allows a safe transport without risk of spillage while the valuable material remains safely cooled at the lowest possible temperature.

The containers of the Auguste Cryogenics Medical Family stand out off through:

High portability thanks to its low weight and compact dimensions
large storage capacity
long holding times

The vacuum-insulated aluminum containers of the Medical Family are thus ideally suited for use in medical institutes, biological laboratories, artificial insemination institutes and pharmaceutical facilities.
The DS containers from the Auguste Cryogenics Medical Family are transportable and have ADR approval.

With the AC Medical Family, Auguste Cryogenics presents its new product line of vacuum-insulated aluminum containers for the transport and storage of nitrogen-cooled material. The products in this group were developed for long holding times with the lowest possible nitrogen consumption. Static holding times from three weeks to over half a year are possible depending on the design and equipment.

The containers of the AC Medical Family can be used in many ways - for insemination as well as in the medical and pharmaceutical sector and for various industrial processes. Biological material can be stored in the liquid or gas phase of the container, depending on the intended use and the temperature requirements.

The products of the DS series complete the AC Medical Family. This Dry Shippers contain a special material that absorbs the liquid nitrogen. This means that the containers can be easily transported on all routes, even by plane.

MDR – Medical Device Regulation (EU)
The Medical Device Regulation (MDR) defines harmonized requirements across Europe for products intended for medical applications. MDR-compliant nitrogen containers meet the highest standards in terms of safety, quality, and documentation, and are specifically designed for use in sensitive environments such as medical, laboratory, and research settings.
They offer verified reliability, compliant design, and full traceability throughout the entire product lifecycle.

Technical Data

AC DS12-S	Part No. H-AAD1100499
LN2 capacity (liters)	4,2
Empty weight (kg)	7,5
Neck opening (mm)	80
Outside diameter (mm)	300
Total height (mm)	630
Static evaporation rate (liters / day)	0,23
Static hold time (days)	35
Effective Shelf Life (days)	25
Canister diameter (mm)	70
Canister height (mm)	120
Canister Number	1
Straw holding capacity 0,25 ml (-S)	625
Straw holding capacity 0,5 ml (-S)	313
ADR	yes
available as an MDR product	yes (optional)
Packing dimensions (mm)	340340640
Shipping volume (m3)	0,74
Weight including packaging (kg)	9,3

* The values given are nominal values, determined without a storage system and under
precisely defined conditions. Depending on the operating conditions and the
storage system used, the actual values may vary considerably.
In the course of continuous product improvement and development,
we reserve the right to change the specifications at any time without prior notice.

Including 1 short canister

Download datasheet:

#searchwords ACDS ACDS12 ACDS12S ACDS12-S DS12 DS12S DS12-S Versand Behälter Trockenversandbehälter Trockenversand Probentrockenversand Zelltrockenversand Transport Probentransport Versand von biogenem Material Aluminiumbehälter kryogene Versandbehälter Kryotransportbehälter Kryorockenversandbehälter Kryobehälter Zelltransport Zellversand Zelltransportbehälter Transport Behälter Transport Zelltransport Probentransport Dryshipper transport container transport cell transport sample transport

Specifications

Incl. 1 short canister

LN2 capacity (liters): 4,2
Empty weight (kg): 7,5
Neck opening (mm): 80
Outside diameter (mm): 300
Total height (mm): 630
Static hold time (days): 35
Effective Shelf Life (days): 25
