The vacuum-insulated aluminum containers of the AC LIN series from the Auguste Cryogenics Medical Family are specifically designed for the storage, dispensing and transport of liquid nitrogen, offering a wide range of applications in laboratories as well as medical, pharmaceutical, and industrial facilities.

Key Features:

High mobility due to low weight and compact dimensions
Long holding times with low nitrogen consumption
T-models with ADR approval – suitable for transport in accordance with dangerous goods regulations

Depending on the model and configuration, static holding times ranging from three weeks to more than six months are possible. These containers are designed for the simple, demand-oriented dispensing of small quantities of liquid nitrogen. The practical containers have capacities ranging from 3 to 100 liters of liquid nitrogen. Containers designated with the “T” suffix are additionally reinforced and comply with ADR regulations for transport on public road and rail networks.

A complete overview of all technical parameters for this container is provided in the “Technical Data” table below.

Overview of further models for NITROGEN STORAGE & TRANSPORT:

AC Liquid Cylinder
Liquid Cylinders are mobile, vacuum-insulated stainless steel pressure vessels designed for the storage and withdrawal of cryogenic liquefied gases. With capacities ranging from 70 to 240 liters, they are suitable for medium-consumption applications and allow withdrawal in both liquid and gaseous phases. Depending on requirements, they are available in low-pressure, pressure-building, medium-pressure, and high-pressure versions. Thanks to their high-quality insulation, they provide low evaporation losses, long holding times, and a flexible supply solution.

AC Micro-Bulk
Micro-Bulk systems are stationary (MBC models) and mobile (TCC models) nitrogen tanks with automatic pressure and fill control for applications with higher consumption. They are available in standard sizes from 600 to 5,000 liters and with working pressures of 8, 11, 24, and 37 bar. Compared to conventional dewars, Micro-Bulk systems offer longer operating times, reduced refilling effort, and a continuous supply of liquid or gaseous nitrogen.

If you need assistance selecting the right container, please contact us directly.

MDR – Medical Device Regulation (EU)
The Medical Device Regulation (MDR) defines binding requirements across Europe for products intended for medical applications. MDR-compliant liquid nitrogen vessels are required for medical and regulated applications where safety, documentation, and traceability are required – for example in hospitals, IVF centers, or biobanks.

Technical Data

AC LIN3	Part No. H-AAD1100119
LN2 capacity (liters)	3
Empty weight (kg)	3,1
Neck opening (mm)	50
Outside diameter (mm)	223
Total height (mm)	435
Static evaporation rate (liters / day)	0,12
Static hold time (days)	26
ADR	yes
available as an MDR product	yes (optional)
Packing dimensions (mm)	270270510
Shipping volume (m3)	0,037
Weight including packaging (kg)	4,8

* The values given are nominal values, determined without a storage system and under
precisely defined conditions. Depending on the operating conditions and the
storage system used, the actual values may vary considerably.
In the course of continuous product improvement and development,
we reserve the right to change the specifications at any time without prior notice.

Download datasheet:

#searchwords ACL ACLIN ACLIN3 LIN LIN3 Aluminium Behälter Aluminium-Behälter Vorratsbehälter Flüssigstickstoffvorrats- und Transportbehälter LN2vorratsbehälter Flüssigstickstoffvorratsbehälter Proben Flüssigstickstoff - Lagerbehälter Flüssigstickstofftank drucklose Behälter Flüssigstickstofftransportbehälter ADR ADR-Zulassung liquid nitrogen storage and transport containers storage container Liquid Nitrogen Containers Liquid Nitrogen Storage Liquid Nitrogen Storage Tank Cryogenic Vessels Liquid Nitrogen Transport and Storage

Specifications

LN2 capacity (liters): 3
Empty weight (kg): 3,1
Neck opening (mm): 50
Outside diameter (mm): 223
Total height (mm): 435
Static evaporation rate (liters/day): 0,12
Static hold time (days): 26
