DS Dry Shipper series for the safe transport of material in cryogenic nitrogen.

The aluminum containers of the DS series from the Auguste Cryogenics Medical Family are cryogenic freezer containers specially designed for the transport of biogenic material in liquid nitrogen. The special material inside the container absorbs the liquid nitrogen and allows safe transport without the risk of spilling, while the valuable material remains safely cooled at the lowest possible temperature. The containers of the DS series can easily be transported on all routes, even by plane.

The DS containers have ADR approval.

The containers of the Auguste Cryogenics Medical Family stand out off through:

High portability thanks to its low weight and compact dimensions
large storage capacity
long holding times

The vacuum-insulated aluminum containers of the Medical Family are thus ideally suited for use in medical institutes, biological laboratories, artificial insemination institutes and pharmaceutical facilities.

#VIALS2mlRack-100-8

Technical Data

AC DS10-B	Part No. H-AAD1100115
LN2 capacity (liters)	3,4
Empty weight (kg)	6,7
Neck opening (mm)	125
Outside diameter (mm)	300
Total height (mm)	623
Static evaporation rate (liters / day)	0,43
Static hold time (days)	23
Effective Shelf Life (days)	8
Racks	1
Dimensions of the racks (mm)	82*84
Box dimensions (mm)	76*76
Levels per rack	4
2ml Vials capacity	100
25 ml blood bag racks (multi)	1
Levels per 25 ml blood bag rack (multi)	1
Boxes per level 25 ml (multi)	3
25 ml blood bag (multi)	3
50 ml blood bag racks (multi)	1
Levels per 50 ml blood bag rack (multi)	1
Boxes per level 50 ml (multi)	3
50 ml blood bag (multi)	3
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	340340630
Shipping volume (m3)	0,071
Weight including packaging (kg)	8,7

#VIALS2mlRack-300-4

Technical Data

AC DS15-B	Part No. H-AAD1100116
LN2 capacity (liters)	6,5
Empty weight (kg)	8,5
Neck opening (mm)	216
Outside diameter (mm)	393
Total height (mm)	580
Static evaporation rate (liters / day)	0,84
Static hold time (days)	18
Effective Shelf Life (days)	4
Racks	1
Dimensions of the racks (mm)	142*144
Box dimensions (mm)	134*134
Levels per rack	3
2ml Vials capacity	300
25 ml blood bag racks (multi)	1
Levels per 25 ml blood bag rack (multi)	1
Boxes per level 25 ml (multi)	15
25 ml blood bag (multi)	15
50 ml blood bag racks (multi)	11
Levels per 50 ml blood bag rack (multi)	3
Boxes per level 50 ml (multi)	15
50 ml blood bag (multi)	15
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	425425655
Shipping volume (m3)	0,118
Weight including packaging (kg)	16,3

#VIALS2mlRack-500-10

Technical Data

AC DS25-B	Part No. H-AAD1100118
LN2 capacity (liters)	9
Empty weight (kg)	15
Neck opening (mm)	216
Outside diameter (mm)	394
Total height (mm)	716
Static evaporation rate (liters / day)	0,89
Static hold time (days)	29
Effective Shelf Life (days)	10
Racks	1
Dimensions of the racks (mm)	142*144
Box dimensions (mm)	134*134
Levels per rack	5
2ml Vials capacity	500
25 ml blood bag racks (multi)	1
Levels per 25 ml blood bag rack (multi)	3
Boxes per level 25 ml (multi)	15
25 ml blood bag (multi)	45
50 ml blood bag racks (multi)	1
Levels per 50 ml blood bag rack (multi)	2
Boxes per level 50 ml (multi)	15
50 ml blood bag (multi)	30
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	425425765
Shipping volume (m3)	0,138
Weight including packaging (kg)	25

#STRAWS025ml-05ml-298-132-8

Technical Data

AC DS3-S	Part No. H-AAD1100110
LN2 capacity (liters)	1,3
Empty weight (kg)	3,2
Neck opening (mm)	50
Outside diameter (mm)	223
Total height (mm)	435
Static evaporation rate (liters / day)	0,17
Static hold time (days)	20
Effective Shelf Life (days)	8
Canister diameter (mm)	38
Canister height (mm)	120
Canister Number	1
Straw holding capacity 0,25 ml (-S)	298
Straw holding capacity 0,5 ml (-S)	132
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	270270510
Shipping volume (m3)	0,037
Weight including packaging (kg)	4,5

#STRAWS025ml-05ml-LongCanister472-214-8

Technical Data

AC DS3-L	Part No. H-AAD1100111
LN2 capacity (liters)	1,3
Empty weight (kg)	3,2
Neck opening (mm)	50
Outside diameter (mm)	223
Total height (mm)	502
Static evaporation rate (liters / day)	0,17
Static hold time (days)	20
Effective Shelf Life (days)	8
Canister diameter (mm)	38
Canister height (mm)	276
Canister Number	1
Straw holding capacity 0,25 ml (-L)	472
Straw holding capacity 0,5 ml (-L)	214
2ml Vials capacity	30
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	270270510
Shipping volume (m3)	0,037
Weight including packaging (kg)	4,5

#STRAWS025ml-05ml-837-374-22

Technical Data

AC DS8-S	Part No. H-AAD1100113
LN2 capacity (liters)	3,2
Empty weight (kg)	6,2
Neck opening (mm)	80
Outside diameter (mm)	300
Total height (mm)	513
Static evaporation rate (liters / day)	0,23
Static hold time (days)	35
Effective Shelf Life (days)	22
Canister diameter (mm)	63
Canister height (mm)	120
Canister Number	1
Straw holding capacity 0,25 ml (-S)	837
Straw holding capacity 0,5 ml (-S)	374
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	340340615
Shipping volume (m3)	0,071
Weight including packaging (kg)	7,3

#STRAWS025ml-05ml-LongCanister3324-854-8

Technical Data

AC DS10-L	Part No. H-AAD1100114
LN2 capacity (liters)	3,4
Empty weight (kg)	6,7
Neck opening (mm)	125
Outside diameter (mm)	300
Total height (mm)	623
Static evaporation rate (liters / day)	0,43
Static hold time (days)	23
Effective Shelf Life (days)	8
Canister diameter (mm)	97
Canister height (mm)	276
Canister Number	1
Straw holding capacity 0,25 ml (-L)	3324
Straw holding capacity 0,5 ml (-L)	854
2ml Vials capacity	210
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	340340630
Shipping volume (m3)	0,071
Weight including packaging (kg)	8,7

#VIALS2mlCanister-210-8

Technical Data

AC DS10-L	Part No. H-AAD1100114
LN2 capacity (liters)	3,4
Empty weight (kg)	6,7
Neck opening (mm)	125
Outside diameter (mm)	300
Total height (mm)	623
Static evaporation rate (liters / day)	0,43
Static hold time (days)	23
Effective Shelf Life (days)	8
Canister diameter (mm)	97
Canister height (mm)	276
Canister Number	1
Straw holding capacity 0,25 ml (-L)	3324
Straw holding capacity 0,5 ml (-L)	854
2ml Vials capacity	210
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	340340630
Shipping volume (m3)	0,071
Weight including packaging (kg)	8,7

#VIALS2mlCanister-114-25

Technical Data

AC DS12-L	Part No. H-AAD1100435
LN2 capacity (liters)	4,2
Empty weight (kg)	7,5
Neck opening (mm)	80
Outside diameter (mm)	300
Total height (mm)	630
Static evaporation rate (liters / day)	0,23
Static hold time (days)	35
Effective Shelf Life (days)	25
Canister diameter (mm)	70
Canister height (mm)	276
Canister Number	1
Straw holding capacity 0,25 ml (-L)	1566
Straw holding capacity 0,5 ml (-L)	671
2ml Vials capacity	114
ADR	yes
available as an MDD product	no
Packing dimensions (mm)	340340640
Shipping volume (m3)	0,74
Weight including packaging (kg)	9,3

#VIALS2mlCanister-30-8

Technical Data

AC DS3-L	Part No. H-AAD1100111
LN2 capacity (liters)	1,3
Empty weight (kg)	3,2
Neck opening (mm)	50
Outside diameter (mm)	223
Total height (mm)	502
Static evaporation rate (liters / day)	0,17
Static hold time (days)	20
Effective Shelf Life (days)	8
Canister diameter (mm)	38
Canister height (mm)	276
Canister Number	1
Straw holding capacity 0,25 ml (-L)	472
Straw holding capacity 0,5 ml (-L)	214
2ml Vials capacity	30
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	270270510
Shipping volume (m3)	0,037
Weight including packaging (kg)	4,5

#STRAWS025ml-05ml-1940-854-8

Technical Data

AC DS10-S	Part No. H-AAD1100398
LN2 capacity (liters)	3,4
Empty weight (kg)	6,7
Neck opening (mm)	125
Outside diameter (mm)	300
Total height (mm)	623
Static evaporation rate (liters / day)	0,43
Static hold time (days)	23
Effective Shelf Life (days)	8
Canister diameter (mm)	97
Canister height (mm)	120
Canister Number	1
Straw holding capacity 0,25 ml (-S)	1940
Straw holding capacity 0,5 ml (-S)	854
ADR	yes
available as an MDD product	yes
Packing dimensions (mm)	340340630
Shipping volume (m3)	0,071
Weight including packaging (kg)	8,7

#STRAWS025ml-05ml-625-313-25

Technical Data

AC DS12-S	Part No. H-AAD1100499
LN2 capacity (liters)	4,2
Empty weight (kg)	7,5
Neck opening (mm)	80
Outside diameter (mm)	300
Total height (mm)	630
Static evaporation rate (liters / day)	0,23
Static hold time (days)	35
Effective Shelf Life (days)	25
Canister diameter (mm)	70
Canister height (mm)	120
Canister Number	1
Straw holding capacity 0,25 ml (-S)	625
Straw holding capacity 0,5 ml (-S)	313
ADR	yes
available as an MDD product	no
Packing dimensions (mm)	340340640
Shipping volume (m3)	0,74
Weight including packaging (kg)	9,3

* The values given are nominal values, determined without a storage system and under
precisely defined conditions. Depending on the operating conditions and the
storage system used, the actual values may vary considerably.
In the course of continuous product improvement and development,
we reserve the right to change the specifications at any time without prior notice.

Including 1 short canister
