1 / 4
AC 160 LP
AC 160 LPItem no. ALC160-0
- LN₂ capacity
- 168L
- Height
- 1,640mm
- Outer Ø
- 508mm
- Empty weight
- 121kg
* Nominal values without storage system installed. Actual capacity may vary depending on configuration.
Sales & service forAuguste Cryogenics
The vessels in the AC Liquid Cylinders Series are storage and transport cylinders for liquefied gas. The product line represent an important component of the Auguste Cryogenics product portfolio. The trusted products have been successfully operating throughout Europe and all over the world for decades.
The inner and outer vessel are constructed of top grade stainless steel. The ultra-low evaporation rates are ensured by a special super insulation and the Auguste Cryogenics GOLD Standard vacuum technology.
Full description
The vessels in the AC Liquid Cylinders Series are storage and transport cylinders for liquefied gas. The product line represent an important component of the Auguste Cryogenics product portfolio. The trusted products have been successfully operating throughout Europe and all over the world for decades.
The inner and outer vessel are constructed of top grade stainless steel. The ultra-low evaporation rates are ensured by a special super insulation and the Auguste Cryogenics GOLD Standard vacuum technology.
Of course all cylinders of the Auguste Cryogenics AC Liquid Cylinder Series comply with the European Directive 2010/35/EU for transportable pressure equipment (TPED), making them flexible and valuable elements in the liquefied gases supply chain in various industrial, medical, research and food production applications.
Auguste Cryogenics‘ AC Liquid Cylinders come in several sizes from 70 to 240 liters net volume and are available without or with pressure building. They are transportable units, designed and built to rugged construction standards that are intended to be carried full. They are engineered for either low-pressure applications of cryogenic filling and liquid dispensing or high-pressure gas distribution. All units feature quick and easy liquid withdrawal.
The road-transportable cylinders are also available equipped with an automatic pressurebuilding circuit. There is also an integrated economizer circuit that helps reduce and control overflow gas consumption. This is designed in order to help conserve gas during low demand periods and build up pressure quickly for peak demand.
The Auguste Cryogenic AC series is the industry standard for gas liquid cylinder performance and feature Auguste Cryogenics‘ GOLD Standard vacuum technology.
Low pressure liquid cylinders
These cylinders are transportable units, designed and built to rugged construction standards that are intended to be carried full of product. These vessels are available with or without a built-in pressure building coil. All units feature quick and easy liquid withdrawal.
Medium and high pressure liquid cylinders
Each vessel in this series of road-transportable cylinders features a pressure building circuit. There is also an integrated economizer circuit that helps reduce and control overflow gas consumption. The optimized design helps to conserve boil off gas during low demand periods and build up pressure quickly for peak demand.
The Auguste Cryogenic AC line represents the GOLD standard for industrial gas liquid cylinder performance.
Specifications
Gross capacity (Liter): 168
Net capacity (Liter): 160
Work. pressure std. | max. (bar): 1.5 | 10
Evaporation on rate (N₂/%/day): 1.5
Liquid withdrawal rate (l/min): 6
Weight empty (kg): 121
Weight filled w. N₂ (kg): 250
Performance
- LN₂ capacity
- 168 L
Further data
- Net capacity
- 160 L
- Working pressure
- 1.5 bar
- Max. pressure
- 10 bar
- Evaporation rate (relative)
- 1.5 %
- Liquid withdrawal rate
- 6 L/min
- Filled weight (N₂)
- 250 kg
- Inner vessel material
- Stainless steel
- Outer vessel material
- Stainless steel
- Insulation
- Multilayer super insulation and high quality vaccuum
- End fitting type
- CGA 295 for N₂, Ar, CO₂ and N₂O | CGA 540 for O₂
Dimensions
- Height
- 1,640 mm
- Outside diameter
- 508 mm
- Empty weight
- 121 kg
Shipping
- Packing dimensions
- 750 × 750 × 1790 mm
- Shipping volume
- 1.01 m³
- Shipping weight
- 141 kg
Order
- SKU
- AC 160 LP
- Item number
- ALC160-0
- ADR
- ADR transportable
- Price
- €7,165.00 excl. VAT
* Nominal values without storage system installed. Actual capacity may vary depending on configuration. Gold values change with your selection.
